HSZ circular electric hoist
1. High efficiency and light pulling force.
2. Safety and reliable to use with low noise, convenient to maintenance.
3. Light in Weight and portable in size.
4. Compact structure and durable.
5. Forged drop Hook.
6. Ratchet type brake warrants, safe and dependable operation..
7. High quality.
Model |
HSZ-0.5 |
HSZ-1 |
HSZ-1.5 |
HSZ-2 |
HSZ-3 |
HSZ-5 |
HSZ-10 |
HSZ-20 |
|
Capacity(t) |
0.5 |
1 |
1.5 |
2 |
3 |
5 |
10 |
20 |
|
lifting height (m) |
2.5 |
2.5 |
2.5 |
2.5 |
3 |
3 |
3 |
3 |
|
test load (t) |
0.75 |
1.5 |
2.25 |
3 |
4.5 |
7.5 |
12.5 |
25 |
|
mini distance between hooks(mm) |
270 |
270 |
368 |
444 |
486 |
616 |
700 |
1000 |
|
chain pull to lift full load(n) |
225 |
309 |
343 |
314 |
343 |
383 |
392 |
392 |
|
no of load chain fall lines |
1 |
1 |
1 |
2 |
2 |
2 |
4 |
8 |
|
dia of load chain (mm) |
6 |
6 |
8 |
6 |
8 |
10 |
10 |
10 |
|
dimension (mm) |
A |
120 |
142 |
178 |
142 |
178 |
210 |
358 |
580 |
|
B |
108 |
122 |
139 |
122 |
139 |
162 |
162 |
189 |
|
C |
24 |
28 |
34 |
34 |
38 |
48 |
64 |
82 |
|
D |
120 |
142 |
178 |
142 |
178 |
210 |
210 |
210 |
Net weight (kg) |
9.5 |
10 |
16 |
14 |
24 |
36 |
68 |
155 |
|
Gross weight (kg) |
12 |
13 |
20 |
17 |
28 |
45 |
83 |
193 |
|
Package Size |
28*21*17 |
30*24*18 |
34*29*20 |
33*25*19 |
38*30*20 |
45*35*24 |
62*50*28 |
70*46*75 |
|
Extra weight per meter (kg) |
1.7 |
1.7 |
2.3 |
2.5 |
3.7 |
5.3 |
9.7 |
19.4 |
