PA500/PA600 Micro Electric Hoist
Product Presentation
The miniature electric hoist design dexterity and easy to use. When the rising weight meets the limiter,the lifting can stop operation automatically. If the wire rope is lifted in reverse, the hoist motor will stopworking automatically. The upper part of hook design of hoist is divided into two states: dynamicloadingand static loading. Domestic 220v power supply operation. The power line is plug-in and easy to use.The hoist' s hook can rotate 360 degrees to prevent the steel rope from rotating.
Technical Parameter
| Model | Method of use | Rated Volt (V) | Input Power (W) | Rated Lifting Weight (kg) | Lifting Speed (m/min) | Lifting Height (m) | Qty/CTN (pcs) | Packing Dimension (cm) | G.W./N.W. (kg) |
| PA500 | Single hook/Double hook | 220 | 1020 | 250/500 | 10/5 | 12/25/306/12.5/15 | 2 | 52×41×17 | 36/34 |
| PA600 | Single hook/Double hook | 220 | 1200 | 300/600 | 10/5 | 12/25/306/12.5/15 | 2 | 52×41×17 | 37/35 |
